Mandrel tube bending

            Equipment-3) Eaton Leonard (L & R) CNC up to 3" VB300, 2)  Eaton Leonard (L & R) CNC up to 3" VB80, 1) Pines non-CNC up to 3", 1) Eaton Leonard
                CNC small tube, 1) Techno CNC up to 5", 1)  Eagle CNC up to 3"
            Tooling-(center line radius in parenthesis, those in bold and underlined are standard for us)
              1"              (1-1/2")

1-1/8"       (2")
              1-1/4"       (2", 2.5")
              1-1/2"       (1.75", 2.25", 3")
              1-5/8"       (2.4375", 3")
              1-3/4"       (1.75", 2.625", 3.5", 4", 6")
              1-7/8        (3")
              2"             (2", 3", 4", 6")

              2-1/8"      (3")
              2-1/4"      (2.25", 3", 3.375", 4.5")
              2-1/2"      (2.5", 3.75", 5", 4")
              2-3/4"      (4.125", 5")
              3"             (3", 4.5", 6", 9")

              3-1/2"      (5.25")
              4"             (6")
              5"             (6", 7.5")
        Mandrel bends
        Multi-bend pipes
        Exhaust systems and kits
Glass packs
        --3", 3-1/2", 4", 5" shells, aluminized or stainless
        --1-3/4", 2", 2-1/4", 2-1/2", 3", 4", 5" cores louvered or perforated
Welded mufflers
        --5-1/2" x 11" body, 14" and 18" long body turbos/welded performance mufflers, aluminized/409 s/s
        --4" x 9" body, 14" long body welded performance mufflers, aluminized/409 s/s
        --5", 6", 7", 8", 10" round
Shrinking/Sizing
        --shrink from 5" to 1-1/4"
        --expand from 1-1/4" to 6" id
        --adapters
Beading
        --hose beads from 1/2" up through 6"
Stainless steel tips
        --custom or off the shelf including 1-1/2", 1-3/4", 2", 2-1/4", 2-1/2", 3", 3-1/2", 4", 5", 6", with various ends
Y, H, X pipes
        --custom or off the shelf
Elliptical bending
Custom exhaust fabrication and installation
Large truck exhaust fabrication and installation
Metal stamping of end caps, baffles, cores, hangers
Side pipes, step bars, dress-up roll bars
Tubing types-round

        --cold rolled
        --aluminized
        --304 stainless
        --409 stainless
Custom mufflers-large or short runs
Custom pipes-large or short runs

--from single bends, to multi-bend tubes, exhaust parts to beaded radiator tubes, we do it all.
Generator mufflers
Water Jet Cutting

--we can water jet cut a wide variety of materials, with stock on a variety of steel, stainless steel, and aluminum.  Short or high volume production runs are available.

Send us a pattern (an o.e. pipe, cardboard cutout, pvc pattern, etc.) and we can duplicate it to your needs. You need to do the finishing (cutting and welding and etc.), but you will have a mandrel bent part. This is excellent for custom applications, or on rare vehicles that require larger or special exhaust.

MISCELLANEOUS EXHAUST ITEMS

We stock a wide variety of exhaust parts that we do not make. These include a full line of chrome tips, hangers, clamps, gaskets, air tubes, catalytic converters, hardware, prebents, mufflers, tubing, and more. If it is an exhaust part, we probably have it available.

Our muffler selection is large, including stock mufflers, turbo style welded and non-welded, universal units, and a variety of welded straight through performance muffler, of which some that are packed with noise suppression material and some without. We offer stainless steel glass packs that we build per specifications, as well as stainless steel turbo mufflers and stainless steel straight through mufflers. With our large muffler selection, we offer a variety of mufflers for any exhaust need and budget.

We also stock direct fit O.E. parts including prebent pipe, catalytic converters and mufflers for stock exhaust replacement. Call us for a specific catalog on any item not included in this catalog, or we can give you specific information on the brands and products that we sell.


INSTALLATION

We have quite the unique muffler shop to handle all your installation needs.  We not only are an exhaust manufacturer, but also a muffler shop.  But unlike most muffler shops, we possess several CNC mandrel tube benders including both a left and right hand CNC mandrel tube bender with up to 3" bending capacity, an xyz measurement laser arm, and a portable measuring  probe arm.  We have several sizing machines, lathes, mills, punch presses, welders, cutters, and many other general manufacturing equipment.  To make it short, we have the equipment to do nearly anything in regards to exhaust.

In our shop we have done the exhaust on a national street rod of the year, an MSRA street rod of the year, as well as many other show-winning automobiles, daily drivers, muscle cars, and other classics.  We have done drag cars, diesels, and even European exotics.  We can use aluminized, 409, or 304 stainless per each customer's request.  For special automobiles, we take the necessary time to do the job as needed for the customer. From aluminized steel to fully-polished mirror-shine 304 s/s exhaust systems, we can do it.  Ample indoor storage is available for those who wish to drop off their vehicle.

All work is charged out on a per man/hour basis, plus the materials used.  Custom exhaust work is very difficult to quote.  Often a general idea of price may be stated, but this will vary based upon the previously mentioned two factors.  We will not give quotes on custom exhaust work!


Heartthrob Exhaust Inc.
60819 U.S. Hwy. 12 West
Litchfield, MN 55355
P:  320-693-0222
F:  320-693-8964
email:  mike@heartthrobexhaust.com
