If you click on the vehicle description it will bring up installation pictures if available.  Click on the part # to bring up the instruction sheets.
Click on these links     to hear sound clips of certain part numbers.

3" CAT-BACK DUAL KITS


Split rear design with 3" mandrel bent aluminized dual tail pipes. Spare tire must be permanently
removed to accommodate this system. Includes either a standard turbo muffler, or now our new
HVS performance muffler. All
necessary pipes, hangers, clamps, muffler, hardware, and instruct-
ions included.  HPM turbo muffler available via special order
.





Application
Standard HVS
Dodge applicaitons:


1994-2001 Dodge Ram w/V6 & V8 & 2-1/2" exhaust at cat
1025500 1025504
2002-2005 Dodge Ram w/V6, 4.7L, 5.9L V8-1/2 ton only 1025510 1025514
2003 Dodge Ram 1/2 ton w/5.7L Hemi only
1025520
1025525
2004-2005 Dodge Ram 1/2 ton w/5.7L Hemi only 1025560
1025565
2006-2008 Dodge Ram 1/2 ton w/5.7L Hemi only   *
1025570  1025575



Ford applications:

1980-1996 Ford F150/F250 w/6 cyl., 302 and 351 V8 w/2-1/4" exhaust at cat*2 1024455
1024459
1997-2003 Ford F150/F250 w/V6 & 4.6L & 5.4L V8-no Super Duty or Lightning 1024555
1024559
2004-2008 Ford F150 w/4.6L, 5.4L-1/2 ton only 1024560
1024564



GM applications:

1988-1993 GM w/350 V8 only and 3" exhaust at cat, 1/2 & 3/4 ton pickup
1028350
1028354
1994-1995 GM w/4.3L V6, 305, 350 V8-muffler-back kit, 1/2 & 3/4 ton pickup 1028351
1028355
1996-1999 GM w/350 V8 and 2" dual at cat-muffler-back kit, 1/2 & 3/4 ton pickup 1029350
1029354
1999-2005 GM w/V6, 4.8L, 5.3L V8 extended/crew cab short box, 1/2 & 3/4 ton pickup 1025750
1025754
1999-2006 GM w/V6, 4.8L, 5.3L V8 reg. cab long box-cat-back kit, 1/2 & 3/4 ton pickup 1025755
1025759
Note: Unless noted, kits are cat-back, fit standard full-sized pickup trucks, fit all wheel bases, both 2wd and 4wd models, 1/2 and light duty 3/4 ton, no diesels, and no V10.
*Note:  for 1025570, 1025575, the spare tire does not need to be pulled.

.                                                                                                         *2Note:  for 1024455 and 1024459, will not fit vehicles with dual fuel tanks

#1024559




2-1/2" CAT-BACK DUAL KITS

Split rear design with 2-1/2" mandrel bent aluminized dual tail pipes. Includes a (HVS) double-wrapped heavy
duty welded performance muffler. All kits are cat-back kits, most convert to single 3" exhaust after the converter
into the muffler. All necessary pipes, hangers, clamps, muffler, hardware, and instructions included.  Pipes
clear standard spare tires and trailer hitches, and fit both 2 and 4 wheel drive models unless noted.  HPM turbo muffler available via special order.  Available in aluminized steel or now new 409 stainless steel.  Note: our new HVS muffler is now standard in all kits, for a deeper, more aggresive sound at the tail pipe, but still nice in the cab.


Application

Aluminized
Part #
Stainless Steel
Part #
Dodge applications:


1990-1991 Dakota w/V6, V8
2005060
N/A
1992-1993 Dakota w/V6, V8 2005070 N/A
1994-1996 Dakota w/V6, V8 2005060 N/A
1997-1999 Dakota w/V6, V8--4WD only 2005050    2405050
2000-2004 Dakota w/V6, V8--4WD only 2005055 2405055
2005-2008 Dakota 131.5" w.b. w/3.7L V6, 4.7L V8 2005080
2405080
1994-2001 Dodge Ram  w/V6 & V8 w/2-1/2" at cat 2005002
2405002
2002-2005 Dodge Ram w/V6, 4.7L, 5.9L V8, 1/2 ton only 2005015
2405015
2003 Dodge Ram w/5.7L Hemi only, 1/2 ton only 2005025
2405025
2004-2005 Dodge Ram w/5.7L Hemi only, 1/2 ton only 2005570 2405570
2006-2008 Dodge Ram w/5.7L Hemi only, 1/2 ton only 2005580   N/A



Ford applications:

1980-1996 Ford F150/F250 w/6 cyl., 302 and 351 V8, w/2-1/4" exhaust at cat-*2 2004402
2404402
1997-2003 Ford F150/F250 w/V6 & 4.6L & 5.4L V8, no Super Duty or Lightning 2004652
2404652
2004-2008 Ford F150 w/4.6L, 5.4L, 1/2 ton only 2004565
2404565
2009-2010 Ford F150 w/4.6L, 5.4L, 1/2 ton only  sound clip of 5.4L V8    2004580
Buy It Now

2011-2013 Ford F150 w/3.5L Ecoboost V6, 1/2 ton only               dyno chart for 3.5L Ecoboost 2004580


2011-2013 Ford F150 w/5.0L V8, 3.7L V6, 1/2 ton only 2004580


GM applications:

1988-1993 GM w/350 V8 only and 3" exhaust at cat, 1/2 & 3/4 ton pickup 2004352
2404352
1994-1995 GM w/4.3L V6, 305, 350 V8, 1/2 & 3/4 ton pickup  2004353
2404353
1996-1999 GM w/350 V8 and 2" dual at cat, 1/2 & 3/4 ton pickup
2002352
2402352
1999-2005 GM w/V6, 4.8L, 5.3L V8 extended/crew cab short box, 1/2 & 3/4 ton pickup
2005722   2405722
1999-2006 GM w/4.8L and 5.3L V8 reg. cab long box, 1/2 & 3/4 ton pickup
2005727 2405727
2001-2006 GM 2500HD and 3500 pickup, 6.0L/8.1L and 3" dual at muffler, crew cab short box 2005810
N/A
2007-2008 GM Silverado 1500 w/4.3L V6, 4.8L, 5.3L, 6.0L V8, crew cab 143.5" w.b., & extended cab std, short, & long box models, 133.9", 143.5", 157.5" w.b.**
2005820
Buy It Now
2405820

2007-2008 GM Silverado 1500 w/4.3L V6. 4.8L, 5.3L, 6.0L V8, regular cab standard box models 119" w.b.** 2005830
Buy It Now
N/A
2009-2014 GM Silverado 1500 w/4.8L, 5.3L, 6.0L V8, crew cab 143.5" w.b., & extended cab std, short, & long box models, 133.9", 143.5", 157.5" w.b.** 2005840
Buy It Now

2009-2012 GM Silverado 1500 w/4.3L V6, 4.8L, 5.3L V8, regular cab 119" w.b. standard box, (78.7" box)
2005850





Toyota applications:


2000-2006 Toyota Tundra w/3.4L, 4.7L ext. cab short box only 2001150 2401150
Note: Unless noted, kits fit standard full-sized pickup trucks, all wheel bases, both 2wd and 4wd models, 1/2 and light duty 3/4 ton, no diesels, and no V10.
**NOTE:  on kit # 2005820 for the 2007 Silverado, we use a specially designed muffler that minimizes interior sound for the displacement on demand engines
*2Note:  for 2004402 and 2404402, will not fit vehicles with dual fuel tanks





2-1/4" CAT-BACK DUAL KITS

Split rear design with 2-1/4" mandrel bent aluminized dual tail pipes. Includes either a standard
turbo muffler, or a (HVS) double-wrapped heavy-duty welded performance muffler, or our HPM
welded performance turbo muffler as a special order.  All kits are cat-back kits, most convert to
single 3" exhaust after the converter into the muffler. All necessary pipes, hangers, clamps, muf-
fler, hardware, and instructions included.   Pipes clear standard spare tires and trailer hitches.





Application Standard HVS
Dodge applications:


1994-2001 Dodge Ram w/V6 & V8 w/2-1/2" at cat
2005000 2005004
2002-2005 Dodge Ram  w/V6, 4.7L, 5.9L V8, 1/2 ton only 2005010 2005014
2003 Dodge Ram 1/2 ton only w/5.7L Hemi only 2005555 2005559
2004-2005 Dodge Ram 1/2 ton only w/5.7L Hemi only 2005565 2005569
2006-2008 Dodge Ram 1/2 ton only w/5.7L Hemi only 2005590 2005596
2009-2014 Dodge Ram 1500 w/5.7L Hemi only and factory dual exhaust *4
dyno chart

2005610




Ford applications:

1980-1996 Ford F150/F250 w/6 cyl., 302 and 351 V8 w/2-1/4" exhaust at cat-*2 2004400
2004404
1997-2003 Ford F150/F250 w/V6 & 4.6L & 5.4L V8-no Super Duty or Lightning
2004655
2004659
2004-2008 Ford F150 w/4.6L, 5.4L-1/2 ton only 2004660
2004665
2009-2010 Ford F150 w/4.6L, 5.4L-1/2 ton only
2004600
2011-2013 Ford F150 w/3.5L Ecoboost V6, 3.7L V6, 5.0L V8-1/2 ton only 2004600
1992-2010 Ford Ranger 2.3L, 3.0L, 4.0L  *3

2007440



GM applications:

1988-1993 GM w/350 V8 only and 3" exhaust at cat , 1/2 & 3/4 ton pickup 2004350
2004354
1994-1995 GM w/4.3L V6, 305, 350 V8, 1/2 & 3/4 ton pickup 2004351
2004355
1996-1999 GM w/350 V8 and 2" dual at cat, 1/2 & 3/4 ton pickup 2002350
2002354
1999-2005 GM w/V6, 4.8L, 5.3L V8 extended/crew cab short box, 1/2 & 3/4 ton pickup 2005720
2005724
1999-2006 GM w/V6, 4.8L, 5.3L V8 reg. cab long box, 1/2 & 3/4 ton pickup 2005725
2005729
Note: Unless noted, kits fit standard full-sized pickup trucks, all wheel bases, both 2wd and 4wd  models, 1/2 and light duty 3/4 ton, no diesels, and no V10 unless noted.
*2Note:  for 2004400 and 2004404, will not fit vehicles with dual fuel tanks
*3Note:  muffler-back kit
*4Note:  this kit replaces the muffler with our HVS welded performance muffler, the factory parts are reused

2-1/4" CAT-BACK REAR SIDE EXIT DUAL KITS

Dual rear design with an exit near stock location and 2-1/4" mandrel bent aluminized dual tail pipes. Includes a (HVS) double-wrapped heavy-duty welded performance muffler.  All kits are cat-back kits, most convert to single 3" exhaust after the converter into the muffler. All necessary pipes, hangers, clamps, muffler, hardware, 2 stainless steel angle cut tips, and instructions included.   Pipes clear standard spare tires and trailer hitches.  These systems are quieter than our other dual systems and 3" single systems.



Application
HVS
GM applications:
2007 GM Avalanche 1500 5.3L, 6.0L 2 & 4WD
2005780
2007 GM Suburban 1500 5.3L 2 & 4WD 2005780


2-1/2" CAT-BACK DUAL SIDE FRONT EXIT KITS

Dual side front exit design with 2-1/2" mandrel bent aluminized dual tail pipes, exiting in front of
passenger side rear wheel. Includes a (HVS) double-wrapped heavy duty welded performance
muffler. All kits are cat-back kits, most convert to single 3" exhaust after the converter into the muf-
fler. All necessary pipes, hangers, clamps, muffler, hardware, and instructions included.  This is
a more aggressive sounding system relative to our other dual kits with mufflers.  Includes two 3"
polished stainless steel tips.  HPM turbo muffler available via special order.  Aluminized steel or
409 stainless steel available.




Application Aluminized
Part #
Stainless Steel
Part #
Dodge applications:

1994-2001 Dodge w/V6 & V8 w/2-1/2" at cat
2005550
2405550
2002-2005 Dodge w/V6, 4.7L, 5.9L V8-1/2 ton only 2005560
2405560



Ford applications:

1980-1996 Ford F150/F250 w/6 cyl., 302 and 351 V8 w/2-1/4" exhaust at cat 2004450
2404450
1997-2003 Ford F150/F250 w/V6 & 4.6L & 5.4L V8-no Super Duty or Lightning 2004460
2404460



GM applications:

1988-1993 GM w/350 V8 only and 3" exhaust at cat , 1/2 & 3/4 ton pickup
2008357
2408357
1994-1995 GM w/4.3L V6, 305, 350 V8, 1/2 & 3/4 ton pickup 2008360
2408360
1999-2005 GM w/V6, 4.8L, 5.3L V8 extended/crew cab short box, 1/2 & 3/4 ton pickup 2008370
2408370
1999-2006 GM w/V6, 4.8L, 5.3L V8 regular cab long box, 1/2 & 3/4 ton pickup 2008376
