If you click on the vehicle description it will bring up installation pictures if available.  Click on the part # to bring up the instruction sheets.

Designed with a stock-type exit behind the passenger side rear wheel with a 3" (or 2-1/2”) mandrel bent aluminized tail pipe. Includes either a standard turbo muffler,  or Heartthrob Velocity Series (HVS) muffler or a (HPM) double-wrapped heavy-duty welded turbo muffler can be special ordered. Most kits are cat-back kits, for 2 & 4WD, manual and auto, convert to single 3" exhaust after the converter into the muffler, and for full-size pickups unless noted. All necessary pipes, hangers, clamps, muffler, hardware, and instructions included.  Applications where HVS muffler does not show an application, it is available via special order.  This is our quietest performance system, other mufflers may be substituted per request.


  Click on these links     to hear sound clips of certain part numbers.


Application Standard   HVS
Buy It Now
Dodge applications:


1990-1991 Dakota V6, V8 2005067 2005069

1992-1993 Dakota V6, V8 2005068
2005072

1994-1996 Dakota V6, V8 2005067 2005069
1997-2000 Dakota V6, V8
2005062

2001-2004 Dakota V6, V8

2005085

2005-2008 Dakota 131.5" w.b. w/3.7L V6, 4.7L V8 2005075
2005076

1994-2001 Dodge Ram  w/V6 & V8, 2-1/2"  at cat
2005500
2005504

2002-2005 Dodge Ram w/V6, 4.7L, 5.9L V8-1/2 ton only 2005510
2005514

2003 Dodge Ram w/5.7L Hemi only, 1/2 ton only 2005515
2005519

2004-2005 Dodge Ram w/5.7L Hemi only, 1/2 ton only 2005575
2005579

2006-2008 Dodge Ram w/5.7L Hemi only, 1/2 ton only 2005595  2005598
1998-2003 Durango 4.7L, 5.2L, 5.9L 2005530
2005534
2004-2009 Durango 3.7L, 4.7L, 5.7L**
2005535





Ford applications:


1980-1996 Ford F150/F250 w/6 cyl., 302 and 351 V8 w/2-1/4" exhaust at cat 2004455
2004459

1997-2003 Ford F150/F250 w/V6 & 4.6L & 5.4L V8-no S.D. or Lightning 2004555
2004559

2004-2008 Ford F150 4.6L, 5.4L 1/2 ton only 2004560
2004570

2009-2010 Ford F150 4.6L, 5.4L  1/2 ton only
2004610 2004615  ***
2011-2014 Ford F150 3.7L V6 1/2 ton only 2004610 2004615
2011-2014 Ford F150 3.5L Ecoboost V6, 1/2 ton only, 4" cat-back single kit*
dyno results for 3.5L Ecooboost, March '11
dyno results for 3.5L Ecooboost, September '11
(sound clip is on 3.5L Ecooboost)                         link to video of install and second dyno test

4004580****

Buy It Now
2011-2014 Ford F150 5.0L V8, 1/2 ton only, 4" cat-back single kit*, note: aggressive interior sound on V8
dyno results for 5.0L           (sound clip is on 5.0L V8)

4004580****

Buy It Now
2011-2014 Ford F150 3.5L Ecoboost V6, 5.0L V8, 4" cat-back single kit*, w/5" s/s tip, 409 s/s kit
4404585

Buy It Now
2000-2005 Excursion 5.4L V8, 6.8L V10, 4 door only 2004470
2004474

2003-2006 Ford Expedition/Lincoln Navigator, 2WD/4WD, 4.6L/5.4L 2004475 2004479

1982-2010 Ranger w/4 cyl. & V6, '94-'09 Mazda B-muffler-back 2007390
2007394





GM applications:



1988-1993 GM w/350 V8 only and 3" exhaust at cat 2008350 2008354
1988-1993 GM w/4.3L V6 & 5.0L V8 only and 2-1/2" exhaust at cat 2008355 2008358

1994-1995 GM w/4.3L V6, 305, 350 V8 2008351 2008356

1996-1999 GM w/350 V8 and 2" dual at cat 2009350 2009354

1999-2006 GM w/V6, 4.8L and 5.3L V8 reg. cab long box 2005715 2005719

1999-2006 GM w/V6, 4.8L and 5.3L V8 reg. cab short box 2005705 2005709

1999-2005 GM w/V6, 4.8L and 5.3L V8 ext./crew cab short box    2005710 2005714
1982-2003 GM S10 pickup w/4 cyl.-muffler back kit 2007350 2007354

1983-1987 GM S10 pickup w/V6.-muffler back kit 2007350 2007354

1988-2003 GM S10 pickup w/V6.-muffler back kit 2007360 2007364

1992-1995 Suburban 5.7L only and 3" exhaust at cat 2008470 2008475

2000-2006 Suburban, Yukon XL 4 door w/5.3L V8 only 2005760 2005764

1996-1999 Suburban w/5.7L w/2" dual exhaust at muffler inlet 2009340 2009345

1994-1995 Suburban 1/2 & 3/4 ton 2WD & 4WD 5.7L w/2-3/4" flanged exhaust at cat
2008400
2008405

1987-1990 Suburban 1/2 ton 2WD 5.7L w/3" exhaust at cat
2008390
2008395

1987-1991 Suburban 1/2 & 3/4 ton 4WD 5.7L w/3" exhaust at cat
2008380
2008385

2000-2006 Tahoe, Yukon w/4.8L, 5.3L 2005765
2005769

2004-2010 Colorado/Canyon w/4 cyl/I5, extended and crew cab models 2007370 2007375
1988-1991 S10 Blazer/Jimmy, 2 & 4 door, V6, 2-1/2” kit 2007380 2007383

1992-1994 S10 Blazer/Jimmy, 2 & 4 door, V6, 2-1/2” kit 2007385 2007387

2001-2006 GM 2500HD and 3500 pickup, 6.0L/8.1L and 3" dual at muffler, crew cab short box* n/a
4005810

2003-2006 GM Hummer H2 6.0L 4 door, dual 3" to muffler, 4" single tail pipe rear exit* n/a
4005800

2007-2010 GM Silverado 2500HD/3500, crew cab std and long box, 6.0L, 2 & 4WD*, 4" single kit

dyno results
n/a
4005815****
buy it now
2007-2010 GM Silverado 2500HD/3500, extended cab std and long box, 6.0L, 2 & 4WD*, 4" single kit n/a 4005835****
2011-2013 GM Silverado 2500HD/3500, crew cab std and long box, 6.0L, 2 & 4WD*, 4" single kit
                                                                                                                      link to youtube video with sound of the kit installed

4005830****
2009-2010 GM Silverado 1500 crew cab short box & extended cab standard box, 143.5" w.b, 6.2L only, 2 & 4WD*, 4" single kit n/a 4005825****
2011-2013 GM Silverado 1500 crew cab short box & extended cab standard box, 143.5" w.b, 6.2L only, 2 & 4WD*, 4" single kit

dyno results
n/a 4005820****


2002-2006 Avalanche, Suburban, Yukon XL 1500 4.8L, 5.3L, 2 & 4WD
2005795

2007-2008 Avalanche 1500 5.3L, 6.0L 2 & 4WD
n/a
2005790
2007-2008 GM Silverado 1500 w/4.3L V6, 4.8L, 5.3L, 6.0L V8  2 & 4WD crew cab 143.5" w.b. models, and ext. cab std, short, & long box models 133.9", 143.5", 157.5" w.b. models**, 3" single kit
n/a
2005805
2007-2008 GM Silverado 1500 w/4.3L V6, 4.8L, 5.3L, 6.0L V8  2 & 4WD crew cab 143.5" w.b. models, and ext. cab std, short, & long box models 133.9", 143.5", 157.5" w.b. models*****, 3.5" single kit

3505805

2009-2014 GM Silverado 1500 w/4.3L V6, 4.8L, 5.3L, 6.0L V8  2 & 4WD crew cab 143.5" w.b. models, and ext. cab std, short, & long box models 133.9", 143.5", 157.5" w.b. models*****, 3.5" single kit
                                                                                                                      link to youtube video with sound of the kit installed

3505815




Jeep applications:


1999-2004 Jeep Grand Cherokee w/4.0L, 4.7L 1022015 1022010

1993-1998 Jeep Grand Cherokee w/4.0L, 5.2L, 5.9L 1022045 1022040

1987-1992 Jeep Cherokee XJ, Wagoneer 4.0L, 2.5L-2-1/2 kit 1022055 1022055V

1993-2001 Jeep Cherokee XJ 4.0L, 2.5L-2-1/2 kit 1022060 1022060V

2002-2007 Jeep Liberty 3.7L V6-2-1/2" kit
1022065 1022068




Toyota applications:


2000-2006 Toyota Tundra w/3.4L, 4.7L extended cab short box only 2001155 2001156
* 4" tail pipe
**note:  uses a specially tuned muffler to help minimize drone and resonance on the displacement on demand engines, this kit is more aggressive than the 2.5" split rear dual.
***note:  aggressive interior sound with this muffler
****note:  uses special 10" round HVS welded muffler, 4" tail pipe
*****note:  uses special round HVS welded muffler, 3.5" tail pipe
